Chapter 5 Host System Configuration
142
Host System Configuration
The Compaq series of line matrix printers do not support the Tandem
Asynchronous Protocol (TAP), or Transparent Tandem Asynchronous
Protocol (T-TAP).
Dataproducts Long Lines Parallel Interface
SYSGEN - Use the 5518 macro name. For a complete list of attributes
for parallel printers, refer to the System Generation manual for
Terminals and Printers (P/N 107875).
NOTE: The EIO Timeout parameter may need to be configured
depending on the speed of the printer.
TCP/IP LAN Configuration
In order to configure a network printer on a Compaq system, a file in
$system.system called “FASTCNFG” must be created. The following is
an example entry in FASTCNFG for the 5525B/31/32 printer:
DEVICE = <$PRINTER NAME>
CONTYPE = TCP/IP
PROTOCOL = MICROPLEX
ADDRESS = <IP ADDRESS>
QUEUENAME = NAME OF PRINT QUEUE>
HOSTNAME = NAME OF SERVER
PORT = 4400
BLOCK = 1024
TIMEOUT = <ADJUST TO AVOID TIMEOUTS> (i.e. 4000)
POLLNUM = 100
IDLETIMEOUT = 60
TCP/IP-A = <PROCESS NAME>
ONLINEMODE = NO/YES (default is NO)
NOTE: In order to configure the printer with the Internal Ethernet
Adapter from the front panel, please refer to page 144.
