Chapter 5 Internal Ethernet Adapter Configuration
144
For a complete list of attributes for nonstandard serial printers, refer to
the System Generation manual for Terminals and Printers (P/N
107875).
Internal Ethernet Adapter Configuration
There are two ways that the Internal Ethernet Adapter can be
configured, either through the front panel or by using dynamic
processes such as Bootp and Rarp. The IPAddress, Subnet Mask, and
the Gateway Address can all be set from the panel.
Ethernet Configuration Using the Printer Front
Panel
Table 8. Ethernet Configuration
Step Key Result Notes
1. Make sure the printer is on. Raise the printer cover.
2.
3. Allows you to make
configuration changes.
4.
5.
6.
7. Selecting www to change.
ON LINE
OFFLINE
CONFIG. CONTROL
+
ENTER SWITCH
UNLOCKED
OFFLINE
CONFIG. CONTROL
UNTIL
OFFLINE
ETHERNET PARAMS
ETHERNET PARAMS
IP Address
IP Address
www.xxx.yyy.zzz
www.xxx.yyy.zzz
www
