Compiling Host Software
149
Table 10. npconfig Detailed Configuration Options Submenu
Option Description
Select Print Server Select the Print Server you want to configure.
Configure Print Server Destination Configure the Internal Ethernet Adapter destination
settings: name, I/O port, model, logpath, state, and
service(s).
Configure Print Server’s Models Configure the Internal Ethernet Adapter model
setting: name, type, banner, page, carriage return
insertion (onlcr), tab expansion (xtab),
descrambling, ASCII to PostScript
conversion
(a2ps), and header and trailer strings.
Configure Print Server’s I/O Ports Configure the Internal Ethernet Adapter port
settings: state, timeout, hand-shaking, parity, and
speed.
Configure Print Server’s Log
Paths
Configure the Internal Ethernet Adapter logpath
settings: name, type, and port.
Configure Print Server’s User’s Add and remove users. Change user passwords
and user types.
Configure Print Server’s Novell
Options
Configure and list the Internal Ethernet Adapter
Novell settings: name, frame type, and PSERVER
password. List Internal Ethernet Adapter PSERVER
and RPRINTER configuration.
Configure Print Server’s Network
Options
Configure and list the Internal Ethernet Adapter IP
address, netmask, routing entries, frame type, and
RARP and BOOTP setting. Restores unit to default
settings. List all network related settings.
Configure Print Server’s System
Information
Display and modify system information of a Print
Server: Internal Ethernet Adapter name, contact
name, location string, log details, descramble key,
license key, and module(s).
