2 Setting Up the Printer
Before You Begin
Read this chapter carefully before installing and operating the printer.
The printer is easy to install. However, for your safety, and to protect
valuable equipment, perform all the procedures in this chapter in the
order presented.
Power Requirements
The printer must be connected to a power outlet that supplies 88 to 135
Volts AC or 178 to 270 Volts AC at 47 to 63 Hz. The printer
automatically senses and adjusts itself to conform to the correct voltage
range.
Primary circuit protection is provided by the power switch, which is also
a circuit breaker. Consult an electrician if printer operation affects local
electrical lines. See “Printer Specifications” on page 207 for additional
power specifications.
IMPORTANT
It is recommended that printer power be supplied from a separate
AC circuit protected at 10 amperes for 120 volts or 5 amperes for
230 volts at 50 or 60 Hertz.
