Internal Ethernet Adapter
173
2. To obtain root access to the unit, type:
supervisor
A standard login screen is displayed prompting you for the login name
and password.
3. Login to the unit as a root user.
root
NOTE: Root users require the use of a password as configured in the
unit’s user list.
4. Enter the password. If this password is not yet set, press enter at
the password prompt. Otherwise, enter the password that is
already stored on the unit.
password
You are now logged in to the unit as a root user and can access any
npsh command on the unit.
NOTE: Because npsh.exe makes use of broadcasts, you may have
problems communicating across a router.
Internal Ethernet Adapter
The Print Server configuration in a Novell environment is much simpler
than that required in a TCP/IP environment. No addresses, masks, or
router entries are necessary and in most cases, the Internal Ethernet
Adapter can simply be connected to the network, turned on, and then
configured for printing from a Novell station through PCONSOLE. The
only parameters that you may want to set are a PSERVER password or
possibly the frame type. This type of configuration is done using
npsh.exe as detailed in the previous section.
