Electrical Characteristics
Input Voltage
Power Consumption
Line Voltage
Design Range
Line
Frequency 500/1000 LPM 1500 LPM
88-135 V RMS 47-63 Hz 6A @ 100 V 8A @ 100 V
178-270 V RMS 47-63 Hz 3A @ 200 V 5A @ 200 V
Operating
Mode
Units Power Consumption
500 LPM 1000 LPM 1500 LPM
Standby
1
Watts 30 (60) 30 (60) 45 (80)
BTU/Hour 100 (205) 100 (205) 154 (273)
Nominal
2
Watts 180 220 310
BTU/Hour 615 750 1058
Maximum
3
Watts 270 315 440
BTU/Hour 920 1075 1500
1
Numbers represent consumption in Power Saver Mode.
Numbers in parenthesis represent standby mode.
2
Nominal power measured at 120 VAC while printing ASCII Shift-Recycle.
3
Maximum power measured at 120 VAC while printing Black Plot.
