Chapter 3 The Control Panel
44
VIEW
In offline or online mode, allows you to view and adjust the placement of
data on the page, or to remove peel-off labels.
With the printer online or offline, press and release to move paper
forward for inspection. The last data printed advances to the tractor
area. Press VIEW a second time to move the paper back to its previous
print position.
If the printer is online and printing, press VIEW to stop printing. The
paper advances. Press
= or > to move 1/72” vertically for fine vertical
forms alignment. Press VIEW. The paper moves back and printing
resumes.
Pressing ON LINE also moves the paper back to its original print
position and returns the printer to online.
CLEAR
Clears a fault message and returns the printer from fault mode to offline
mode.
After correcting the fault, press and release. The fault message is
cleared, and the printer returns to offline mode.
Other functions:
• Moves to the top of the configuration menu when the printer is in
the configuration menus.
• Cancels data in the buffer. Place the printer offline. From the host
system, stop the print job. Press CLEAR+ENTER. Reset the top-of-
form (page 38).
• Press SHIFT+CLEAR to reset the PCL-II emulation.
