Chapter 3 The Control Panel
46
UP or DOWN ( = or > )
Moves up and down between levels in the configuration menus and
makes vertical forms adjustment. After pressing VIEW, press
= or > to
adjust the paper up or down in 1/72 inch increments for fine vertical
forms alignment. After pressing ON LINE, press
= or > to move through
levels in the configuration menus.
UP + DOWN (
= + > )
Locks and unlocks the ENTER key.
PREV or NEXT (
; or < )
Moves between the options on the current level of configuration menu.
In the configuration menu press
; to scroll backward or press < to scroll
forward through the menu selections on the same level.
PREV + NEXT (
; + < )
When both keys are pressed simultaneously, the printer performs a soft
reset of the LP+ emulation and the printer buffers are cleared.
