Chapter 4 Configuration Overview
66
The parameters you have changed remain active as long as the printer
is on. When you turn off the printer, the parameters are erased from
memory unless you save them in a configuration. If you do not save the
configuration, the printer reverts to the default values next time the
printer is powered on.
The next section, “Saving Your New Configuration”, will explain how to
save configurations.
Saving Your New Configuration
Once you have changed all of the necessary parameters, it is
recommended you save them as a configuration that can be stored and
loaded for future use. If you do not save your configuration before you
power off the printer, all of your parameter changes are erased. The
Save Config. option allows you to save up to eight configurations to
meet different print job requirements. (Configurations 1 through 8 are
empty until you save values to them using the Save Config. option.)
13. Slow Paper Slew
Enable*
The * indicates this choice
is active.
14. ENTER SWITCH
LOCKED
Locks the ENTER key.
15. ONLINE
LinePrinter+
Places the printer in
online mode.
16. Close the printer cover. The printer is ready for operation.
Step Press LCD Notes
ENTER
+
ON LINE
