Chapter 4 Configuration Overview
68
8. Save Config.
2*
The * indicates this choice
is active.
NOTE: It is recommended you print the configuration. To print the configuration go to Step 9. To
skip this procedure and resume printer operation, go to Step 14.
9. CONFIG. CONTROL
Save Config.
10. CONFIG. CONTROL
Print Config.
11. Print Config.
Current
12. Print Config.
2
Press until the desired
parameter displays.
13. OFFLINE
CONFIG. CONTROL
The selected
configuration is printed.
14. ENTER SWITCH
LOCKED
Locks the ENTER key.
15. ONLINE
LinePrinter+
16. Close the printer cover. If you printed out the configuration, store it in a safe place. The printer is
ready for operation.
Step Press LCD Notes
ENTER
UNTIL
OR
ENTER
+
ON LINE
