Chapter 4 CONFIG. CONTROL
72
Save Config.
This option allows you to save up to eight unique configurations to meet
different print job requirements. This eliminates the need to change the
parameter settings for each new job. The configurations are stored in
memory, and will not be lost if you turn off the printer. If the Protect
Configs. parameter is enabled, the new configuration will not be saved
unless the existing configuration has been deleted first. The factory
default configuration cannot be changed. See “Saving Your New
Configuration” on page 66 for details.
Print Config.
This option is used to print a listing of various stored printer
configurations. It is recommended you store printouts of your
configurations in a safe place for quick referral.
Delete Config.
You can delete one or all of your eight customized configurations. The
factory default configuration cannot be deleted.
Power-Up Config.
You can specify which of the nine configurations (Factory or 1-8) will be
the power-up configuration.
Protect Configs.
You can specify whether or not a new configuration should overwrite an
existing configuration when you activate the Save Configs. parameter.
When disabled (default), the new configuration will overwrite the
existing configuration. When enabled, the new configuration will
not
overwrite the existing configuration, and the message “CONFIG.
EXISTS / Delete First” displays.
