73
ACTIVE EMULATION
The ACTIVE EMULATION function allows you to activate either the
PCL-II or LinePrinter Plus emulation, as well as the optional IGP/PGL or
IGP/VGL emulations, if they are installed. There are two methods for
selecting the desired emulation. The first is by selecting the emulation
directly from the printer menu. The second is by sending a host
command which will switch the emulation automatically (see the
appropriate
Programmer’s Reference Manual
for details
).
When changing from one emulation to the other, the printer will load the
power-up configuration. Thus, any configuration settings performed
before selecting these emulations and not saved in NVRAM will be lost.
IMPORTANT
In order to configure an emulation, the emulation must be selected
in the ACTIVE EMULATION menu. The emulation that is not
selected will not appear in the EMULATION menu (see
“EMULATION” on page 74).
ACTIVE
EMULATION
(from page 69)
PCL-II*
LP PLUS IGP/PGL
1
IGP/VGL
1
* = Factory Default
1
Optional Emulation
