Chapter 4 EMULATION
78
PTX Linefeed
• Disable. The default. Linefeed is performed as calculated from the
bottom of the graphics or barcode, thereby disrupting the vertical
text alignment.
• Enable. The Linefeed moves to the next line as calculated from the
Top of Form position, thereby retaining vertical text alignment.
When printing graphics or bar codes, you may want to set the PTX
Linefeed parameter to Enable to maintain text alignment.
LPI Adjust
This parameter lets you specify the lines per inch (lpi) values, 6 LPI (the
default) or 8 LPI.
Page Length Adjust/Lines
This parameter lets you set physical page length from 1 to 128 lines.
The default is 66 lines.
Page Length Adjust/Inches
This parameter lets you set physical page length from 2 to 16 inches, in
increments of half an inch. The default is 11 inches.
Config. Print
This option prints the emulation’s parameters and the currently selected
values.
Symbol Set Print
This option prints a list of all the available sets. The character set
number prints to the left of the character set sample.
PTX Linefeed Enabled PTX Linefeed Disabled
LINE 1
LINE 2
LINE 3
Linefeed
Linefeed
LINE 1
LINE 2
LINE 3
