Proprinter XL Emulation
87
Proprinter XL Emulation
Define CR Code
This option controls the action of the printer when it receives a Carriage
Return code (hex 0D) from the host computer. If this feature is enabled,
each time the printer receives a Carriage Return, it inserts an additional
Line Feed code (hex 0A) into the data stream. Do not use this feature if
the host computer sends Line Feeds to the printer.
• CR = CR. Does not insert an extra Line Feed after each Carriage
Return.
• CR = CR + LF. Inserts an extra Line Feed after each Carriage
Return.
Printer
Protocol
(from page 79)
Define CR
Code
Auto LF
Define LF
Code
FF Valid at
TOF
Character Set Alt. Char Set
20 CPI
Condensed
CR = CR*
CR = CR + LF
Enable*
Disable
LF = LF*
LF = CR + LF
Enable*
Disable
Code Page 437*
Code Page 850
OCR-A
OCR-B
Latin 2 8859-2
Latin 2 852
Bulgarian
Latin 0 8859-15
Set 1*
Set 2
Enable*
Disable
* = Factory Default
Proprinter XL
