Chapter 4 EMULATION
92
Character Set
Specifies a character set. To use one of these sets, choose the desired
character set and press ENTER.
Note that when OCR-A or OCR-B is selected as the print language, the
Font Attribute Typeface option under the LinePrinter Plus menu (page
80) is changed to OCR-A or OCR-B, respectively.
20 CPI Condensed
Compressed print characters are narrower than the normal character
set. This is helpful for applications where you need to print the
maximum amount of information on a page.
• Enable. Prints about 60 percent of the width of normal characters
when compressed print is chosen by the host computer. For
example, a 12 CPI Draft font will compress to 20 CPI.
• Disable. Does not compress print widths, even if condensed print is
chosen by the host.
Alternate Set 80-9F
• Control Code. Interprets data in the range of hex 80 through hex
9F as a control code.
• Printable. Prints data in the range of hex 80 through hex 9F.
