Chapter 4 EMULATION
96
Define CR Code (Carriage Return)
This parameter forces the printer to insert an automatic Line Feed code
into the data stream whenever a Carriage Return code occurs. This is
to be used only if the host computer does not send Line Feeds to the
printer.
• CR = CR. Does not perform a line feed. The next print position will
be print position 1 of the current line.
• CR = CR + LF. Performs an automatic line feed. The next print
position will be print position 1 of the next line.
Define LF Code (Line Feed)
This parameter forces the printer to insert an automatic Carriage Return
code into the data stream whenever a Line Feed code occurs. This can
be used in most installations, but it is required if the host computer does
not send Carriage Returns to the printer.
• LF = LF. Does not perform an automatic carriage return. The next
print position will be the current print position of the next line.
• LF = CR + LF. Performs an automatic carriage return. The next
print position will be print position 1 of the next line.
Autowrap
This parameter determines if text will wrap to the next line when the line
of text exceeds the right margin.
• Disable. Truncates the text beyond the right margin until a CR or
CR + LF is received.
• Enable. Automatically inserts a CR + LF after a full print line.
Select SFCC
You can specify which decimal code (1-255) will be used as the Special
Function Control Code (SFCC). The factory default setting is 126. The
SFCC denotes that the following data is an IGP/PGL command.
