Asynchronous Terminals and Printer Processes Configuration and Management Manual

Managing ATP6100 Using the
Subsystem Control Facility (SCF)
Asynchronous Terminals and Printer Processes Configuration and Management Manual—424280-003
6-4
ATP6100 Subsystem Objects
ATP6100 Subsystem Objects
The SCF objects for the ATP6100 subsystem correspond to process components
within the subsystem. There are three CP6100 object types:
•
PROCESS
•
LINE
•
SU
Figure 6-2 shows the ATP6100 subsystem objects supported by SCF and their
hierarchical order
PROCESS Object
The PROCESS object defines an ATP6100 process. The PROCESS name is the
same as the name of the LINE it controls. The PROCESS can be addressed by using
line-name as follows: PROCESS line-name.
LINE Object
LINE is a communications line. The LINE name identifies the specific ATP6100 line
configured in the system and assigned through the WAN subsystem. The LINE name
must be unique in a system, be preceded by a dollar sign ($), and consist of a
maximum of seven alphanumeric characters with no embedded blanks; the first
character must be alphabetic, for example, $ATPS1.
Figure 6-2. ATP6100 Subsystem Object Hierarchy
VST0602.vsd
LINE
SU
PROCESS
