Asynchronous Terminals and Printer Processes Configuration and Management Manual

Configuration Quick Start
Asynchronous Terminals and Printer Processes Configuration and Management Manual—424280-003
1-2
Log On to the NonStop Server and Obtain
SWAN/SWAN 2 Information
Log On to the NonStop Server and Obtain
SWAN/SWAN 2 Information
1. Log on to the Integrity NonStop NS-series or NonStop S-series server using the
Super ID and enter the correct password at the Password: prompt.
> LOGON super.super
Password:
2. At the TACL prompt on the Integrity NonStop NS-series or NonStop S-series
server, start SCF:
> SCF
3. Find an available WAN line on the SWAN/SWAN 2 concentrator by issuing the
STATUS ADAPTER command:
-> status adapter $zzwan.#*, sub all
WAN Manager STATUS ADAPTER for ADAPTER \TEST.$ZZWAN.#S01
State........... STARTED
Number of clips. 3
Clip 1 status : CONFIGURED
Clip 2 status : CONFIGURED
Clip 3 status : CONFIGURED
WAN Manager STATUS SERVER for CLIP \TEST.$ZZWAN.#S01.1
State :......... STARTED
Path A..........: CONFIGURED
Path B..........: CONFIGURED
Number of lines. 2
Line............ 0 : $S01P1
Line............ 1 : FREE
WAN Manager STATUS PATH for PATH \TEST.$ZZWAN.#S01.1.A
State :......... STARTED
MEDIA TYPE...... ETHERNET
MEDIA ADDRESS... %H08008E004814
WAN Manager STATUS PATH for PATH \TEST.$ZZWAN.#S01.1.B
State :......... STARTED
MEDIA TYPE...... ETHERNET
MEDIA ADDRESS... %H08008E004815
WAN Manager STATUS TASK for TASK \TEST.$ZZWAN.#S01.1.DIAG
State :......... STOPPED
WAN Manager STATUS TASK for TASK \TEST.$ZZWAN.#S01.1.DLC0
State :......... STARTING
WAN Manager STATUS TASK for TASK \TEST.$ZZWAN.#S01.1.DLC1
State :......... STARTING
a. Record the name of the SWAN/SWAN 2 concentrator
(\system.$zzwan.#conc-name) in the adapter field in Example 1-1,
Adding an ATP6100 Device, on page 1-4. (For example: S01.)
b. Record the CLIP containing the available WAN line in the clip-num field in
Example 1-1, Adding an ATP6100 Device. (For example: 1.)
