Asynchronous Current Loop Only Port Module
Asynchronous Current Loop Only Port Module
The Asynchronous Current Loop port module is a port module dedicated only to Current
Loop; 16 ports are provided. Each port has a data-transfer rate of up to 19.2 Kbps.
Figure 1-4
shows the panel of a Current Loop only port module.
V.34 Analog Modem Port Module
The V.34 Analog Modem port module provides eight V.34 modems. Each modem has a
data-transfer rate of up to 115.2 Kbps. The modem connect speed is a maximum of 33.6
Kbps.
Figure 1-5
shows the panel of a V.34 Analog Modem port module.
Figure 1-4. Current Loop Only Port Module
Figure 1-5. V.34 Analog Modem Port Module
066CDT .CDD
20ma CURR
LOOP
12345678
9 10111213141516
020CDT .CDD
V.34
ANALOG
MODEM
12345678
