Introduction to the AWAN Access Server
AWAN 3883/4/5 Access Server Installation and Support Guide—424241-001
1-7
IDSN BRI Port Module
IDSN BRI Port Module
The ISDN BRI port module provides six basic-rate ISDN connections.
Figure 1-6
shows the panel of an ISDN BRI port module.
Panel Indicators
This subsection describes the front and back panel indicators of each AWAN access
server model. Refer to this information during the installation procedure. The
installation procedure is described in Section 2, Installing the AWAN Access Server
.
Model 3883-8, 3883-8R, 3883-16, and 3883-16R Panel Indicators
The front panel of models 3883-16 and 3883-16R is shown in Figure 1-7.
Table 1-3
describes the LED indicators on the front panel of models 3883-8, 3883-8R,
3883-16, and 3883-16R.
Figure 1-6. ISDN BRI Port Module
Figure 1-7. Model 3883-16 and 3883-16R Front Panel
026CDT .CDD
ISDN
BRI
123456
CDT005.CDD
PWR
ACT
1
2
3
