Introduction to the AWAN Access Server
AWAN 3883/4/5 Access Server Installation and Support Guide—424241-001
1-11
Model 3884 and 3884R Panel Indicators
Power Receptacle This is a grounded, three-wire receptacle for AC with an integral fuse
holder. It accepts the AC power cord supplied with the AWAN access
server.
Fuse Holder This is a fuse holder that uses an F1.6A 250 volt (5x20 mm) fast-
blow fuse. A compartment for a spare fuse is located in the holder.
On/Off Switch This is a rocker switch for turning AC power on and off. Press the
topside side [l] of the switch to turn power on and the bottom side
[O] of the switch to turn power off.
Table 1-6. Rear Panel Components (Models 3884 and 3884R)
Component Description
