AWAN 3883/4/5 Access Server Installation and Support Guide

Installing the AWAN Access Server
AWAN 3883/4/5 Access Server Installation and Support Guide—424241-001
2-5
Environmental, Temperature, and Humidity
Specifications
Environmental, Temperature, and Humidity Specifications
Table 2-4 provides environmental, temperature, and humidity specifications for each
AWAN access server model.
Complete hardware specifications for each AWAN access server model are provided in
Appendix A, Hardware Specifications
.
Table 2-3. Compaq Adapters
Adapter Hood Type Purpose
Compaq Part
Number
RS-232 Console
Adapter*
This RS-232 adapter hood connects a terminal or
PC to the console port or to an RS-232 port.
U37450-A00
RS-232 Modem/Host
Adapter
This RS-232 modem/host adapter hood is designed
to be used with existing terminal or modem
cabling.
U37451-A00
CL 25 Host Adapter This Current Loop host adapter hood works with
existing customer cables. Cables may be
unplugged from a 6100 communications
subsystem (CSS) controller and plugged into this
adapter.
U37393-A00
CL 9 Host Adapter This Current Loop host adapter hood works with
existing customer cables. Cables may be
unplugged from a 3650 CSS controller and
plugged into this adapter.
U37392-A00
*One RS-232 Console Adapter is shipped with the AWAN access server.
Table 2-4. Environmental, Temperature, and Humidity Specifications
Models 3883-8,
3883-8R, 3883-16, and
3883-16R
Models 3884 and
3884R
Models 3885 and
3885R
Environment 0°-45° C (32°-113° F) 0°-40° C (32°-104° F) 0°-40° C (32°-104° F)
Temperature 10-90% noncondensing 10-90% noncondensing 10-90% noncondensing
Humidity Meets FCC Part 15,
Class A specifications.
Meets FCC Part 15,
Class A specifications.
Meets FCC Part 15,
Class A specifications.
