Installing the AWAN Access Server
AWAN 3883/4/5 Access Server Installation and Support Guide—424241-001
2-9
Installing an AWAN Access Server
Installing an AWAN Access Server
This subsection describes how to install an AWAN access server.
Installation Steps
To install an AWAN access server, perform the following steps:
1. Connect the supplied AC power cord between the AWAN access server and a
grounded AC receptacle.
2. Connect the Ethernet cable. The AWAN access server supports connection to one
Ethernet cable configuration at a time.
3. Power on the AWAN access server using the power switch on the rear panel of the
chassis.
Note. If you are installing a model 3884, 3884R, 3885, or 3885R AWAN access server, you
should install your link modules and port modules before performing the following procedure.
Note. When installing a redundant power supply, both power-supply AC cords must be
plugged in. The power supply automatically adapts the unit to the type of incoming voltage
(110 VAC or 220 VAC) by sensing the voltage and adjusting the circuitry to operate at that
voltage. No manual switching is required.
