Maintaining the AWAN Access Server
AWAN 3883/4/5 Access Server Installation and Support Guide—424241-001
3-3
Replacing a Fuse
7. Replace the power cable and turn the power on.
Figure 3-2. Plastic Fuse Holder and Spare Container
Note. If the replacement fuse blows, there may be an electrical fault within the AWAN access
server. Do not attempt to disassemble and repair the AWAN access server; contact your
Compaq support representative.
012CDT .CDD
Spare fuse
Active
fuse
Lip for removal
Side view
Top view
