Maintaining the AWAN Access Server
AWAN 3883/4/5 Access Server Installation and Support Guide—424241-001
3-4
Removing an AWAN Access Server
Removing an AWAN Access Server
To remove an AWAN access server, perform the following steps:
1. Verify that all port users have disconnected their sessions.
2. Power off the AWAN access server using the power off switch on the rear panel of
the chassis.
3. Verify that all power is disconnected and that you are properly grounded.
4. Disconnect the Ethernet cable.
5. Disconnect any attached devices.
6. If you will be replacing the AWAN access server, follow the instructions in
Section 2, Installing the AWAN Access Server
.
Note. Failed AWAN access server hardware should be returned using the normal Logistics
channels or normal return department.
