AWAN 3883/4/5 Access Server Installation and Support Guide—424241-001
A-1
A
Hardware Specifications
This appendix provides detailed hardware specifications for each AWAN access server
model.
Item
3883-8, 3883-8R,
3883-16, and
3883-16R 3884 and 3884R 3885 and 3885R
Ports For models 3883-8 and
3883-8R: Eight RS-232
RJ-45 connectors with
full modem control.
For models 3883-16
and 3883-16R: Sixteen
RS-232 RJ-45
connectors with full
modem control.
Sixteen RS-232 RJ-45
connectors with full
modem control.
Eight-port integrated
V.34 modems.
Six-port ISDN BRI.
Sixteen RS-232/20mA
Current Loop RJ-45
connectors.
Sixteen RS-232 RJ-45
connectors with full
modem control.
Eight-port integrated
V.34 modems.
Six-port ISDN BRI.
Sixteen RS-232/20mA
Current Loop RJ-45
connectors.
Link Modules N/A One link module can
be installed on the
chassis.
One link module can
be installed on the
chassis.
Port Modules N/A Up to two port modules
can be installed on the
chassis.
Up to four port
modules can be
installed on the chassis.
Speeds LAN speeds up to 10
Mbps and port
operation at speeds up
to 115.2 Kbps.
LAN speeds up to 10
Mbps and port
operation at speeds up
to 115.2 Kbps.
LAN speeds up to 10
Mbps and port
operation at speeds up
to 115.2 Kbps.
Weight 5 lbs. 8 lbs. 10 lbs.
Dimensions Height: 1.75 inches
Width: 16.75 inches
Depth: 12 inches
Height: 3.48 inches
Width: 17.25 inches
Depth 16.43 inches
Height: 5.22 inches
Width: 17.25 inches
Depth: 16.43 inches
Flow Control XON/XOFF, RTS/CTS XON/XOFF, RTS/CTS XON/XOFF, RTS/CTS
Power Supply Single universal input,
85-264 VAC, 50-60 Hz,
automatically self-
sensing.
Single universal input,
85-264 VAC, 50-60 Hz,
automatically self-
sensing.
Single or redundant
universal input, 85-264
VAC, 50-60 Hz,
automatically self-
sensing.
Front Panel Eight or sixteen status
LEDs, power/fault
indicator, and Ethernet
activity indicator.
Fourteen LEDs: power,
link module activity,
port module activity,
and fault indicators.
Nineteen LEDs: active
power supply, link
module activity, port
module activity, and
fault indicators.
