AWAN 3883/4/5 Access Server Installation and Support Guide

AWAN 3883/4/5 Access Server Installation and Support Guide—424241-001
Index-1
Index
Numbers
10Base-T (twisted-pair) cable 2-4
3883 models
features 1-2
location of console port on 1-9
location of factory configuration button
on 1-9
panel indicators on 1-7
3884 models
features 1-2
location of console port on 1-14
location of factory configuration button
on 1-14
panel indicators on 1-9
3885 models
console port location on 1-14
features 1-3
location of factory configuration button
on 1-14
panel indicators on 1-12
A
Adapters
pinouts, hood C-1
/C-5
types of 2-4/2-5
Asynchronous RS-232/20mA Current Loop
port module, description of 1-5, 1-6
AUI transceiver cable 2-3
AWAN access server
installing 2-9
removing 3-4
C
CL 25 Host Adapter 2-5
CL 9 Host Adapter 2-5
Console port
connecting a terminal of PC to 2-10
location of
3883 models 1-9
3884 and 3885 models 1-14
Current Loop only port module 1-6
D
DB-25 adapter hood pinouts
host, Current Loop C-3
, C-4
modem/host, RS-232 C-3
printer, RS-232 C-2
terminal, RS-232 C-2
DB-9 adapter hood pinouts
host, Current Loop C-5
PC, RS-232 C-1
Devices, connecting 2-10
Dimensions, AWAN access server A-1
E
Environmental specifications 2-5
Ethernet LAN link module, description
of 1-4
F
Factory configuration button, location of
3883 models 1-9
3884 and 3885 models 1-14
Flow control A-1
Fuse, replacing 3-2
H
Hardware specifications A-1/A-2
Humidity specifications 2-5
