C/C++ Programmer's Guide (G06.27+, H06.03+)
Table Of Contents
- What’s New in This Manual
- About This Guide
- 1 Introduction to HP C and C++ for NonStop Systems
- TNS C Language System
- TNS C++ Language System
- TNS/R Native C and C++ Language System
- TNS/R Native C Compiler
- TNS/R Native C++ Compiler
- TNS/R Native C Run-Time Library
- C++ Run-Time Library and Standard C++ Library
- TNS/R Native Linkers (nld and ld Utilities)
- Inspect Symbolic Debugger
- Visual Inspect Symbolic Debugger
- TNS/R Native Object File Tool (noft Utility)
- NonStop SQL/MP Compiler and NonStop SQL/MX Compiler
- TNS/R Native C and C++ Migration Tool
- Features of TNS/R Native C and C++
- TNS/E Native C and C++ Language System
- TNS/E Native C Compiler
- TNS/E Native C++ Compiler
- TNS/E Native C Run-Time Library
- C++ Run-Time Library and Standard C++ Library
- TNS/E Native Linker (eld Utility)
- Native Inspect Symbolic Debugger
- Visual Inspect Symbolic Debugger
- TNS/E Native Object File Tool (enoft Utility)
- NonStop SQL/MP Compiler and NonStop SQL/MX Compiler
- TNS/E Native C and C++ Migration Tool
- Features of TNS/E Native C and C++
- Writing Portable Programs
- Porting Programs to HP C and C++ for NonStop Systems
- Porting Without Data Alignment Problems
- Guardian and OSS Environment Interoperability
- 2 C and C++ Extensions
- 3 Interfacing to Guardian Procedures and OSS Functions
- 4 Using the C Run-Time Library
- 5 Using the Standard C++ Library
- 6 Accessing Middleware Using HP C and C++ for NonStop Systems
- 7 Mixed-Language Programming for TNS Programs
- 8 Mixed-Language Programming for TNS/R and TNS/E Native Programs
- 9 System-Level Programming
- 10 Converting C-Series TNS Programs to Use the Current TNS Compiler
- 11 Migrating Programs to TNS/R or TNS/E Native Mode
- 12 Preprocessor Directives and Macros
- 13 Compiler Pragmas
- ALLOW_CPLUSPLUS_COMMENTS
- ALLOW_EXTERN_EXPLICIT_INSTANTIATION
- ANSICOMPLY
- ANSISTREAMS
- BUILD_NEUTRAL_LIBRARY
- CALL_SHARED
- CHECK
- COLUMNS
- CPATHEQ
- CPPONLY
- CSADDR
- ELD(arg)
- ENV
- ERRORFILE
- ERRORS
- EXTENSIONS
- EXTERN_DATA
- FIELDALIGN
- FORCE_VTBL
- FORCE_STATIC_TYPEINFO
- FORCE_STATIC_VTBL
- FUNCTION
- HEADERS
- HEAP
- HIGHPIN
- HIGHREQUESTERS
- ICODE
- IEEE_FLOAT
- INLINE
- INLINE_COMPILER_GENERATED_FUNCTIONS
- INLINE_LIMIT
- INLINE_STRING_LITERALS
- INNERLIST
- INSPECT
- KR
- LARGESYM
- LD(arg)
- LINES
- LINKFILE
- LIST
- LMAP
- MAP
- MAPINCLUDE
- MAXALIGN
- MIGRATION_CHECK
- NEST
- NEUTRAL
- NLD(arg)
- NOEXCEPTIONS
- NON_SHARED
- OLDCALLS
- OLIMIT
- ONCE
- OPTFILE
- OPTIMIZE
- OVERFLOW_TRAPS
- PAGE
- POOL_STRING_LITERALS
- POP
- PUSH
- REFALIGNED
- REMARKS
- RUNNABLE
- RUNNAMED
- RVU
- SAVEABEND
- SEARCH
- SECTION
- SHARED
- SQL
- SQLMEM
- SRL
- SRLExportClassMembers
- SRLExports
- SRLName
- SSV
- STDFILES
- STRICT
- SUPPRESS
- SUPPRESS_VTBL
- SYMBOLS
- SYNTAX
- SYSTYPE
- TANDEM_FLOAT
- TRIGRAPH
- VERSION1
- VERSION2
- VERSION3
- WARN
- WIDE
- XMEM
- XVAR
- 14 Compiling, Binding, and Accelerating TNS C Programs
- 15 Compiling, Binding, and Accelerating TNS C++ Programs
- 16 Compiling and Linking TNS/R Native C and C++ Programs
- 17 Compiling and Linking TNS/E Native C and C++ Programs
- 18 Using ETK and Native C/C++ Cross Compiler on the PC
- 19 Running and Debugging C and C++ Programs
- 20 TNS C Compiler Messages
- 21 Native C and C++ Compiler Messages
- 22 Run-Time Messages
- 23 Handling TNS Data Alignment
- A HP C Implementation-Defined Behavior
- Implementation-Defined Behavior of Native C
- G.3.1 Translation
- G.3.2 Environment
- G.3.3 Identifiers
- G.3.4 Characters
- G.3.5 Integers
- G.3.6 Floating Point
- G.3.7 Arrays and Pointers
- G.3.8 Registers
- G.3.9 Structures, Unions, Enumerations, and Bit Fields
- G.3.10 Qualifiers
- G.3.11 Declarators
- G.3.12 Statements
- G.3.13 Preprocessing Directives
- G.3.14 Library Functions
- G.4 Locale Behavior
- G.5 Common Extensions
- Translation Limits for Native C Compilers
- Implementation-Defined Behavior of TNS C
- G.3.1 Translation
- G.3.2 Environment
- G.3.3 Identifiers
- G.3.4 Characters
- G.3.5 Integers
- G.3.6 Floating Point
- G.3.7 Arrays and Pointers
- G.3.8 Registers
- G.3.9 Structures, Unions, Enumerations and Bit Fields
- G.3.10 Qualifiers
- G.3.11 Declarators
- G.3.12 Statements
- G.3.13 Preprocessing Directives
- G.3.14 Library Functions
- G.4 Locale Behavior
- G.5 Common Extensions
- Implementation-Defined Behavior of Native C
- B TNS C++ ImplementationDefined Behavior
- C ASCII Character Set
- D Data Type Correspondence
- E Features and Keywords of Version2NativeC++
- F MIGRATION_CHECK Messages
- Glossary
- Index
HP C/C++ Programmer’s Guide for NonStop Systems—429301-010
15-1
15
Compiling, Binding, and
Accelerating TNS C++ Programs
•
Working in the Guardian Environment
°
C Preprocessor Cprep on page 15-3
°
C++ Translator Cfront on page 15-6
°
TNS C Compiler Run Command Syntax on page 15-8
°
File Formats on page 15-10
°
Compiling a Sample C++ Program on page 15-10
°
Error Messages in the Guardian Environment on page 15-11
°
Binding C++ Programs on page 15-12
•
Working in the G-Series OSS Environment on page 15-14
°
TNS c89 Flags on page 15-15
°
TNS c89 Operands on page 15-16
°
Input Files on page 15-17
°
Binding on page 15-17
°
Examples on page 15-17
°
Error Messages in the OSS Environment on page 15-18
Working in the Guardian Environment
To create an executable TNS C++ program in the Guardian environment:
1. Run the C preprocessor Cprep
2. Run the C++ translator Cfront
3. Run the C compiler
4. Run the Binder
5. Run the Accelerator or Object Code Accelerator (OCA) (optional)
This section describes each compilation step, including the purpose of the compilation,
the output from the compilation, and the syntax description for the compilation run
command. This section also contains an example that shows you how to compile a
simple TNS C++ program.
You can use a separate run command for each of the C++ compilation steps, as
described in this section and shown in the compilation example, or you can use a
TACL macro to consolidate these compilation steps.
If you use a TACL macro to drive the C++ compilation, you still need to understand
what is needed for each compilation step, what is accomplished by each compilation
