ADM-2 Multipoint Supervisor Protocol
Envoy Application Programming Manual—427159-001
7-43
Sending a Broadcast-Select Message
Sending a Broadcast-Select Message
Example 7-21 shows the line-control sequence to send a broadcast-select message
formatted by Envoy to all terminals in the network.
Example 7-21. Send a Broadcast-Select Message
Application Process Network
line state = CONTROL
MCW.<6> = 1 (message type = special)
MCW.<5> = 0 (message formatter = Envoy)
MCW.<8:15> = 0 (clear entry number)
CALL WRITE(..);
| EOT 11t22t33s STX-text-ETX ->
| <- ACK
(WRITE completes)
error = 0
line state = CONTROL
