Writing a Command-Interpreter Monitor ($CMON)

Guardian Programmer’s Guide — 421922-014

23 - 18

Controlling Process Creation

The structure of the Processcreation^msg message is as follows:

Format of command-interpreter message -52 (Processcreation^msg message):

STRUCT PROCESSCREATION^MSG;

BEGIN

INT MSGCODE; ![0] value -52

INT USERID; ![1] user ID or user logged on

INT CIPRI; ![2] initial priority of command

! interpreter

INT CIINFILE[0:11]; ![3] name of command file for

! TACL process

INT CIOUTFILE[0:11]; ![15] name of list file for

! TACL process

INT PROGNAME[0:11]; ![27] program-file name

INT PRIORITY; ![39] priority specified in RUN

! command if supplied;

! otherwise -1

INT PROCESSOR; ![40] processor number specified

! RUN command if supplied;

! otherwise -1

INT PROGINFILE[0:11]; ![41] the expanded IN file RUN

! parameter if supplied;

! otherwise the default IN

! file

INT PROGOUTFILE[0:11]; ![53] the expanded OUT file RUN

! parameter if supplied;

! otherwise the default OUT

! file

INT PROGLIBFILE[0:11]; ![65] the expanded LIB file RUN

! parameter if supplied;

! otherwise blanks

INT PROGSWAPFILE[0:11]; ![77] the expanded SWAP file RUN

! parameter if supplied;

! otherwise blanks

INT PARAM_LEN; ![89] length of PARAM in bytes.

STRING PARAM[0:MAX^PARAM - 1];

![90] parameter string of the RUN

! command, which is up to

528

! bytes in length including

! null bytes at the end of

the

! string.

END;

Note. The CIIN file name supplied in the process creation message is in local format even if

the TACL process is remote. This means that the file name does not contain the node number.

The $CMON process can get the node number of the CIIN file by calling LASTRECEIVE (or

RECEIVEINFO) to get the process ID of the TACL that sent the process creation message; the

process ID contains the node number of the TACL, which is the same as the node number of

the CIIN file.
