Glossary

Guardian Programmer’s Guide — 421922-014

Glossary - 30

TNS code segment identifier

TNS code segment identifier. A seven-bit value in which the most significant two bits

encode a code space (user code, user library, system code, or system library) and the

five remaining bits encode a code segment index in the range 0 through 31.

TNS code segment index. A value in the range 0 through 31 that indexes a code segment

within the current user code, user library, system code, or system library space. This

value can be encoded in five bits.

TNS code space. One of four addressable collections of TNS object code in a TNS

process. They are User Code (UC), User Library (UL), System Code (SC), and System

Library (SL). UC and UL exist on a per-process basis. SC and SL exist on a per-node

basis.

TNS compiler. A compiler in the TNS development environment that generates 16-bit TNS

object code following the TNS conventions for memory, stacks, 16-bit registers, and

call linkage. The TNS C compiler is an example of such a compiler. Contrast with

TNS/E native compiler.

TNS Emulation Library. A public dynamic-link library (DLL) on a TNS/E system containing

the TNS Object Code Interpreter (OCI), millicode routines used only by accelerated

mode, and millicode for switching among interpreted, accelerated, and native

execution modes. See also Shared Millicode Library.

TNS emulation software. The set of tools, libraries, and system services for running TNS

object code on TNS/E systems and TNS/R systems. On a TNS/E system, the TNS

emulation software includes the TNS Object Code Interpreter (OCI), the TNS Object

Code Accelerator (OCA), and various millicode libraries. On a TNS/R system, the TNS

emulation software includes the TNS Object Code Interpreter (OCI), the Accelerator,

and various millicode libraries.

TNS instructions. Stack-oriented, 16-bit machine instructions that are directly executed on

TNS systems by hardware and microcode. TNS instructions can be emulated on

TNS/E and TNS/R systems by using millicode, an interpreter, and either translation or

acceleration. Contrast with

reduced instruction-set computing (RISC) and Intel®

Itanium® instructions.

TNS interpreted mode. A TNS emulation environment on a TNS/E system in which

individual TNS instructions in a TNS object file are directly executed by interpretation

rather than permanently translated Intel® Itanium® instructions. TNS interpreted mode

runs slower than TNS accelerated mode. Each TNS instruction is decoded each time it

is executed, and no optimizations between TNS instructions are possible. TNS

interpreted mode is used when a TNS object file has not been accelerated for that

hardware system, and it is also sometimes used for brief periods within accelerated

object files. Accelerated or interpreted TNS object code cannot be mixed with or called

by native mode object code. See also TNS Object Code Interpreter (OCI). Contrast

with TNS accelerated mode, TNS/R native mode, and TNS/E native mode.
