Communicating With Printers

Guardian Programmer’s Guide — 421922-014

11 - 13

Using Job-Control Commands

The following example selects the manual paper feed as the paper source:

SBUFFER ':=' [%33,"&l2H"] -> @S^PTR;

CALL WRITEX(PRINTER^NUM,SBUFFER,@S^PTR '-' @SBUFFER);

IF <> THEN ...

Selecting the Output Bin

You select the output bin by writing an escape sequence with the following format to

the printer:

bin-number is 1 for the upper bin and 2 for the lower bin.

The following example selects the lower bin:

SBUFFER ':=' [%33,"&l2G"] -> @S^PTR;

CALL WRITEX(PRINTER^NUM,SBUFFER,@S^PTR '-' @SBUFFER);

IF <> THEN ...

Separating Jobs

You issue the job separation sequence by writing an escape sequence with the

following format to the printer:

The following issues the job separation sequence:

SBUFFER ':=' [%33,"&l1T"] -> @S^PTR;

CALL WRITEX(PRINTER^NUM,SBUFFER,@S^PTR '-' @SBUFFER);

IF <> THEN ...

3 Manual envelope feed

4 Lower paper tray

6 Envelope feeder

Escape sequence for selecting the output bin:

esc&lbin-numberG

Note. Bin selection is supported only on laser printers that support PCL 5.

Escape sequence for selecting the output bin:

esc&l1T

Note. The job separation feature is supported only on the PCL 5 laser printers.
