Using the FML Buffer Type●

Using the VIEW Buffer Type

(Note that X_COMMON and X_C_TYPE are used identically to VIEW.)

●

For information about all of the NonStop

TUXEDO typed buffers, data types, and buffer types, refer to the NonStop

TUXEDO Application

Programming Guide and the NonStop

TUXEDO Reference Manual.

Of the NonStop

TUXEDO built-in buffer types, the Jolt application programmer should be particularly aware of how Jolt handles the CARRAY

(character array) and STRING built-in buffer types. The CARRAY type is used to handle data opaquely, (that is, the characters of a CARRAY data

type are not interpreted in any way). Data conversion is not performed between a Jolt client and NonStop

TUXEDO service.

For example, if a NonStop

TUXEDO service uses a CARRAY buffer type and the user sets a 32-bit integer (in Java the integer is in big-endian

byte order), then the data is sent unmodified to the NonStop

TUXEDO service. If the NonStop

TUXEDO service is run on a machine whose

processor uses little-endian byte-ordering (that is, Intel processors), the NonStop

TUXEDO service must convert the data properly before the data

can be used.

Using the STRING Buffer Type

The STRING buffer type is a collection of characters. STRING consists of non-null characters and is terminated by a null character. The STRING

data type is character and, unlike CARRAY, you can determine its transmission length by counting the number of characters in the buffer until

reaching the null character.

Note

During the data conversion from Jolt to STRING, the null terminator is automatically appended to the end of the STRING

buffers because a Java string is not null-terminated.

Example 6-1 illustrates how Jolt works with a service whose buffer type is STRING. The TOUPPER NonStop

TUXEDO Service is available in

the NonStop

TUXEDO simpapp example.

Define TOUPPER in the Repository Editor

Before running Example 6-2, you need to define the TOUPPER service through the Jolt Repository Editor:

Note

If you are not familiar with using the Jolt Repository Editor, refer to Adding a Service and Adding a Parameter for more

information about defining your services and adding new parameters.

Using the Jolt Repository Editor, define the TOUPPER service for the SIMPSERV package.1.
