N1526A and N1527 ACL Tape Drive Installation and User's Guide
Table Of Contents
- What’s New in This Manual
- About This Manual
- 1 Overview and Features
- 2 Setting Up the ACL Tape Drives
- 3 Installing and Configuring the ACL Tape Drive for the NonStop S-Series Server
- 4 Operation
- 5 Maintenance
- 6 Troubleshooting
- A Specifications
- Safety and Compliance
- Index
N1526A and N1527A ACL Tape Drive Installation and User’s Guide—542756-003
1-1
1 Overview and Features
This section includes:
Overview
The auto cartridge loader (ACL) tape drives support the LTO Ultrium Gen 2 tape drive.
They are designed for backup operations for NonStop servers. The N1526A comes in
a rackmount configuration, and the N1527A comes in a tabletop configuration.
NonStop S-Series Servers
These auto cartridge loader tape drives connect to a ServerNet/DA, IOMF2 CRU, or
PMF CRU
on the NonStop S-series server by a SCSI cable. Figure 1-1 shows how
the ACL tape drives connect to the NonStop S-series server.
Overview 1-1
Models and Accessories 1-3
Internal Tape Drive 1-3
Magazine 1-4
Power Supply 1-4
Robotics 1-4
Front Panel Indicators 1-6
