Overview and Features
N1526A and N1527A ACL Tape Drive Installation and User’s Guide—542756-003
1-2
NonStop NS-Series Servers
NonStop NS-Series Servers
An M8201R Fibre Channel to SCSI router must be used to connect the tape drives to
the Fibre Channel ServerNet Adapter (FCSA) on the HP NonStop NS-series server.
For more information, see the M8201R Fibre Channel to SCSI Router Installation and
User’s Guide and the Fibre Channel ServerNet Adapter Installation and Support
Guide.
Figure 1-1. Hardware Configuration
NonStop S-Series
Tape Drive
SCSI Cable
ServerNet/DA,
IOMF2 CRU, or
PMF CRU
Server
