Overview and Features
N1526A and N1527A ACL Tape Drive Installation and User’s Guide—542756-003
1-6
Front Panel Indicators
Front Panel Indicators
The ACL tape drive’s front panel indicators consist of:
•
Viewing window: lets you visually check the unit’s internal operations
•
GUI touch screen: manually operated to setup and configure the unit
•
ACL module status LED: displays the unit’s operational status
Figure 1-5. Front Panel Indicators
ACL Status LED GUI Touch Screen Internal Viewing
Window
