NonStop Cluster Performance Essentials User's Guide, Version 2.2

(2) For SIM v5.3:

------------

a) Use the top SIM Menu: Options -> Discovery, click on "New"

Note: You may use automatic discovery, but manual discovery seems to work

best.

b) Give a name to this discovery task and type in the IP address of the agent.

c) Uncheck "Automatically execute discovery every _ minutes"

Note: Unchecking this option seems to work best.

d) Click on "Credentials" and supply the sign-in credentials for the agent.

e) Click on 'Show advanced protocol credentials', go to the 'WBEM' tab and

provide the username and password for the agent.

Note: It is not required to enter the Port number.

f) Click "OK" and "Save".

g) A new entry should be created in the Discovery table. Select the “discovery

task” that was created and click “Run Now”

h) Do this for all agents you have running.

[Back to TOC]

4.3.6. Removing Agents (Nodes)

Removing a node from the monitoring list can be done by deleting the node from

SIM or removing it from the cluster. To remove a node from SIM, simply select the

node by clicking the corresponding checkbox in SIM’s main table and click “Delete”.

To remove a node from a cluster, the user will need to use the HP Cluster

Configuration Management application. After doing this, use Refresh PE… to update

this change to Performance Essentials.

NOTE: The above process does NOT remove the agent software from the

corresponding server nor does it stop the collection on the server. To stop collection

on the servers: on the NonStop obey the stoppe script (obey stoppe), on the Linux

server, kill the collator, collector, PAMAuth and License handler processes.

To remove the agent software from the servers: on the NonStop purge the files in

the installation subvolume, on Linux run rpm –e simagent-0.1.i386.

[Back to TOC]
