Group, Module, and Slot Hierarchy for IOAM
Enclosures
IOAM Configuration Requirements
Configuring IOAM enclosures on a NonStop S-series system includes the following
requirements:
•
An IOAM enclosure can be group 11, 12, 13, 14, or 15. Each one takes the place
of up to four I/O enclosures.
•
IOAM enclosures can be installed in any order.
•
MSEB slots corresponding to the group 01 slot in which the IOAM is installed must
be empty.
•
When installing IOAM enclosures in the field, install them in an available location.
Any I/O enclosure groups that are not allowed must be removed or moved to
another location.
If necessary, move I/O enclosures in your system as follows:
Cabling IOAM enclosures is illustrated in Cabling IOAM Enclosures on page 4-76
For an IOAM enclosure cabling diagram, see or Cabling Diagram, IOAM Enclosure, X
Fabric on page 5-19.
To add an IOAM
enclosure as group ...
You must vacate any I/O enclosures from these groups so
the IOAM enclosure can be connected to the corresponding
MSEB ports...
11 21, 31, 41
12 22, 32, 42
13 23, 33, 43
14 24, 34, 44
15 25, 35, 45
