Initial Configurations
HP NonStop S-Series Planning and Configuration Guide—523303-015
8-3
Processor Types and Memory Sizes
Processor Types and Memory Sizes
This table lists the memory sizes available for each processor type. The processors
within a system are not required to have the same amount of memory. However, if you
are planning for a system containing processors with different memory sizes, you might
want to perform a capacity analysis to ensure that, in the event of a processor failure,
the backup processor can maintain an adequate performance level for the increased
load.
For more information about the memory in NonStop S-series servers, see Memory on
page 4-39.
Internal Disk Drives
Each NonStop S-series system enclosure can contain up to 16 internal disk drives.
Supported Internal Disk Drives
The internal disk drives supported in all NonStop S-series system enclosures for the
current RVU are listed in Internal Disk Drives on page F-4.
Disk Drives for 16-GB Processors
To perform an online memory dump of a 16-GB processor to a disk volume using
RECEIVEDUMP or RCVDUMP, you must have one 36-GB or larger disk drive in which
20 GB is reserved for memory dump. The remaining storage space can be used for
anything. This disk does not have to be $SYSTEM.
NonStop S-Series Processor Type
Memory
1950
S7000
1960
S7400
1961
S7600
1962
S7800
1951
S70000
1954
S72000
1970
S74000
1971
S76000
1972
S86000
1973
S78000
1974
S88000
128 MB * *
256 MB X X X
512 MB X X X X X
1 GB X X X X X
2 GB X X X X X
4 GB X X X X X X X
8 GB XX
16 GB X X X
* 128 MB memory is not supported for PMF CRUs on G06.16 and later.
