Initial Configurations
HP NonStop S-Series Planning and Configuration Guide—523303-015
8-4
Minimum Disk-Drive Configuration
Minimum Disk-Drive Configuration
A system must include a minimum of four internal disk drives, all having the same
product number. This table lists the factory-default device name, location, and purpose
of each of these four internal disk drives.
Locations of $DSMSCM and $AUDIT as Mirrored Volumes
HP recommends that you configure $DSMSCM and $AUDIT as mirrored volumes. This
table lists the locations of $DSMSCM and $AUDIT if they are configured as mirrored
volumes.
Other Internal Disk Drives
Any other internal disk drives that are ordered are also configured and named at the
factory. To determine the factory-default configuration of a systems’s internal disk
drives, after you install and start your system, use SCF to determine the system
configuration. Refer to the SCF Reference Manual for G-Series RVUs for more
information about this task.
The two physical disk drives of a mirrored volume must have the same product number
(except during an online upgrade).
Factory Default
Device Name Location Purpose
$SYSTEM-P Group 01, module 01, slot 11 Contains files related to the
operating system (primary drive
of mirrored volume)
$SYSTEM-M Group 01, module 01, slot 12 Contains files related to the
operating system (mirror drive of
mirrored volume)
$DSMSCM Group 01, module 01, slot 13 Contains the Distributed
Systems Management/Software
Configuration Manager
(DSM/SCM) database files, the
CIIN file, and the CONFTEXT
configuration file
$AUDIT Group 01, module 01, slot 14 if
nonmirrored; see Locations of
$DSMSCM and $AUDIT as
Mirrored Volumes on page 8-4
Contains HP NonStop
Transaction Management Facility
(TMF) audit-trail files, and the
archive files of DSM/SCM
Device Name Location Purpose
$DSMSCM-P Group 01, module 01, slot 13 Primary drive
$DSMSCM-M Group 01, module 01, slot 14 Mirror drive
$AUDIT-P Group 01, module 01, slot 15 Primary drive
$AUDIT-M Group 01, module 01, slot 16 Mirror drive
