Completing the Installation Plan
HP NonStop S-Series Planning and Configuration Guide—523303-015
13-11
Preinstalled I/O Device Cable Checklist
Preinstalled I/O Device Cable Checklist
If you have already installed I/O device cables for use with this system, use the
Preinstalled I/O Device Cable Checklist to tell the installer which cables are to be
connected to the system equipment being installed.
(This information also included in the Floor Plan.)
Complete a Preinstalled I/O Device Cable Checklist as follows.
The column headed by a check mark is provided for you to check off each line item to
make certain that all required preinstalled I/O device cables are installed and ready for
operation.
Task Comments
Enter the name of the system in the
System Name column.
This system name must match the system name
on all other forms in this packet.
Enter the information from the cable
ID tag in the Cable ID Tag column.
The cable ID tag is the physical label attached to
the I/O device cable.
In the Floor Plan field, describe the
location of the cable.
If the room contains only one preinstalled cable,
listing the room number is sufficient. Otherwise,
provide a more detailed description.
Enter the page number of this page
and the total number of pages of this
form in the Page ___ of ___ field.
Some forms are designed to be duplicated.
When you have completed this form,
enter the date in the Date field.
