System Enclosure Checklist
System Enclosure Checklist
The System Enclosure Checklist tells the installer what configurable items were
ordered and are installed in each processor enclosure and I/O enclosure.
Make a copy of this form for each system enclosure in the configuration you are
documenting.
Complete the System Enclosure Checklist as follows.
Task Comments (page 1 of 2)
Enter the name of the system in the System Name field. This system name must match
the system name on all other
forms in this packet.
Enter the group number of the enclosure in the Group
Number field.
Complete the Appearance Side area of the form:
For each disk drive in the enclosure, in the illustration of
the disk drive slot, enter:
Logical device name
Product number
Make entries only for those disk
drives you are ordering.
If this form is for group 01:
Enter “$SYSTEM-P” and its product number in slot 11
and enter “$SYSTEM-M” and its product number in
slot 12.
Enter logical device names and product numbers for the
disk volumes $DSMSCM and $AUDIT in the appropriate
slots.
Complete the Service Side area of the form:
For processor enclosures:
In slots 50 and 55: enter “PMF.” You might also want to
enter the processor number for each processor.
In slots 51 through 54:
If the slot will contain a ServerNet adapter, enter the
name and type of the ServerNet adapter.
If the slot will contain an SEB or MSEB, enter “SEB.”
If the slot will not contain a ServerNet adapter, enter
“filler panel.”
