PMF CRU Configuration Forms
PMF CRU Configuration Forms
The PMF CRU Configuration Form and PMF 2 CRU Configuration Form tell the
installer about each PMF CRU in the system and the configurable items associated
with it. These completion instructions apply to both forms.
Task Comments (page 1 of 2)
Enter the name of the system in the
System Name field.
This system name must match the system name
on all other forms in this packet.
Enter the group number of the
enclosure that contains this PMF CRU
in the Group field.
Enter the slot number of this PMF CRU
in the Slot field.
If you are attaching a tape drive to the
SCSI port on this PMF CRU, complete
the SCSI Port block:
1. In the Product Number field, enter
the product number of the tape
drive.
2. In the SCF Name field, enter the
SCF object name of the tape drive.
3. In the SCSI Cable field, enter the
part number of the SCSI cable you
will use with this tape drive.
If you are not attaching a tape drive to the SCSI
port on this PMF CRU, leave the SCSI Port block
empty.
