IOMF CRU Configuration Forms
IOMF CRU Configuration Forms
The IOMF CRU Configuration Form and IOMF 2 CRU Configuration Form tell the
installer about each IOMF CRU in the system and the configurable items associated
with it. These instructions apply to both forms.
Task Comments
Enter the name of the system in the System
Name field.
This system name must match the
system name on all other forms in this
packet.
Enter the group number for the enclosure that
contains this IOMF CRU in the Group field.
Enter the slot number of this IOMF CRU in the
Slot field.
Complete the ServerNet Connection block:
In the ServerNet Cable field, enter the part
number of the ServerNet cable that connects to
this IOMF CRU.
In the ServerNet Connector field, enter the
ServerNet connector on the SEB to which this
cable connects.
In the Group and Slot fields, enter the group and
slot numbers of the SEB to which this cable
connects.
If you are attaching a tape drive to the SCSI port
on this IOMF CRU, complete the SCSI Port
block:
In the Product Number field, enter the product
number of the tape drive.
In the SCF Name field, enter the SCF object
name of the tape drive.
In the SCSI Cable field, enter the part number of
the SCSI cable you will use with this tape drive.
If you are not attaching a tape drive to
the SCSI port on this IOMF CRU, leave
the SCSI Port block empty.
Leave the Ethernet Port block empty. You cannot use the Ethernet port on
IOMF CRUs at this time.
When you have completed this form, enter the
date in the Date field.
