Cross-Row Cabling Worksheets
Cross-Row Cabling Worksheets
The cross-row cabling worksheets are provided to help you determine the number and
type of ServerNet cables that you need to cable a system with enclosures arranged in
multiple rows. These worksheets are used with the ServerNet Cabling Forms
described on page 13-23.
The following worksheets are located in alphabetic order in Appendix C, Blank Forms:
Complete a cross-row cabling worksheet as follows.
Cross-Row Cabling Worksheet, SEB to IOMF CRU
Cross-Row Cabling Worksheet, SEB to SEB
Task Comments
Make photocopies of the cross-row
cabling worksheets you need.
On each ServerNet cabling form, enter
the system name and Page _ of _.
This system name must match the system name
on all other forms in this packet.
Enter the group numbers of the two
enclosures in the From group _ and to
_ group fields.
Enter the width of the service aisle
Check the boxes on the worksheet that
describes the enclosures that are to be
cabled together and enter the
corresponding measurements on the
worksheet.
Add all the measurements in the
column and enter that value in the Total
Cable Length field.
Enter the part number of this cable in
the Cable Part Number field.
When you have completed this form,
enter the date in the Date field.
