Part Numbers
HP NonStop S-Series Planning and Configuration Guide—523303-015
A-2
NonStop S-Series Enclosures
NonStop S-Series Enclosures
System Components
Cables and Cable Assemblies A-26
AC Power Cords, Enclosures Without Power Shelves A-29
AC Power Cords, Enclosures With Power Shelves A-30
Note. Each part number follows one of two numbering systems:
•
Old Tandem part numbers start with 0 or 1.
•
HP part numbers start with T or U.
All part numbers contain nine digits. (Only the first six digits are shown in these tables.) Any of
these types of part numbers might appear on a part number label.
Description Product Number
Single-high enclosure with base 7193
Double-high enclosure with base 7194
Add-on enclosure without base 7195
Second visual image single-high enclosure with base 7280
Second visual image double-high enclosure with base 7281
Second visual image add-on enclosure without base 7282
Description Part Number (page1of2)
AWAN servers and Related Components See page A-17
AC power cords, enclosures without or with power shelves See pages A-29 and A-30
Battery, FRU (48 V, 2.5 A) 429555
(was 124838)
Battery retainer U24884
DC power cable FRU (servers with power shelves) U25206
Disk drives, internal See page A-7
Disk drives, external See page A-7
Doors See page A-5
Electrostatic discharge (ESD) protection kit T99247
Ethernet switch or hub See page A-20
Fan U27555
Fuse, 10 A, 60 V, (for DC-DC converter board on S7400,
S7600, and Sxx000 PMF CRUs)
U25184
IOMF CRU See page A-5
Loopback test equipment See page A-13
