Part Numbers
HP NonStop S-Series Planning and Configuration Guide—523303-015
A-4
Memory
Memory
1970-C 2 GB 425692
1970-D 4 GB 425693
S76000 1971-B NSR-X 1 GB 429955
1971-C 2 GB 424403
1971-D 4 GB 429956
1971-E 8 GB 527446
1971-F 16 GB 429957
S78000 1973-C NSR-H 2 GB 526490
1973-D 3 GB 526491
1973-E 4 GB 526492
S86000 1972-B NSR-Y 1 GB 523621
1972-C 2 GB 524397
1972-D 4 GB 523622
1972-E 8 GB 527445
1972-F 16 GB 523623
S88000 1974-C NSR-Z 2 GB 526493
1974-D 4 GB 526494
1974-E 8GB 526495
1974-F 16 GB 526496
* The two versions of 1951 PMF CRUs do not have fixed memory configurations.
** A model 1954 PMF CRU contains commercially available dual inline memory modules (DIMMs). DIMMs are
not interchangeable with memory units manufactured by HP. The LMUs on this PMF CRU can contain different
sizes of memory units.
† 128 MB memory is not supported for PMF CRUs on G06.16 and later
.
Description Part Number
Memory units:
8-megabyte MDC U07560
32-megabyte MDC U06628
128-megabyte MDC U29000
512-megabyte MDC U24852
Memory DIMMs:
32-megabyte EDO 60 ns U35093
128-megabyte EDO 60 ns U32163
256-megabyte EDO 50 ns U42443, 421601
Server PMF CRU Processor Type Memory Size
Part Number
(page 2 of 2)
