Specifications
HP NonStop S-Series Planning and Configuration Guide—523303-015
B-5
ServerNet Cables for Same-Row Connections
SEB-to-IOMF CRU Connections in Same Row
You need these ServerNet cables for each SEB-to-IOMF-CRU or MSEB-to-IOMF CRU
connection within a row of enclosures.
Arrangement
of
Enclosures
Distance
Between
Connections
Cable Length
Required Part Number
Spaced Feet Meters Feet Meters
ECL
SEB to
SEB
ECL
SEB to
MSEB
ECL
MSEB to
MSEB
Serial
Copper
Vertically
0 8.2 2.5 8.2 2.5 U26027 427047 427029 U26027
Horizontally
0 6.2 1.9 8.2 2.5 U26027 427047 427029 427226
1 8.2 2.5 8.2 2.5 U26027 427047 427029 427226
2 10.0 3.1 9.8 3.0 U24316 427048 427030 421580
3 11.9 3.6 13.1 4.0 U24317 427049 427031 427227
4 13.7 4.2 16.4 5.0 U24319 427050 427032 421581
5 15.6 4.7 16.4 5.0 U24319 427050 427032 421581
6 17.4 5.3 19.7 6.0 U30033 427051 427033 427228
7 19.2 5.9 19.7 6.0 U30033 427051 427033 427228
8 21.1 6.4 23.0 7.0 U30034 427052 427034 427229
9 22.9 7.0 23.0 7.0 U30034 427052 427034 427229
10 24.7 7.5 26.2 8.0 U30035 427053 427035 427230
Diagonally
0 9.5 2.9 9.8 3.0 U24316 427048 427030 421580
1 11.5 3.5 13.1 4.0 U24317 427049 427031 427227
2 13.3 4.1 16.4 5.0 U24319 427050 427032 421581
3 15.2 4.6 16.4 5.0 U24319 427050 427032 421581
4 17.0 5.2 19.7 6.0 U30033 427051 427033 427228
5 18.8 5.7 19.7 6.0 U30033 427051 427033 427228
6 20.7 6.3 23.0 7.0 U30034 427052 427034 427229
7 22.5 6.9 23.0 7.0 U30034 427052 427034 427229
8 24.3 7.4 26.2 8.0 U30035 427053 427035 427230
9 26.2 8.0 26.2 8.0 U30035 427053 427035 427230
10 28.0 8.5 29.5 9.0 U30036 427054 427036 427231
