NonStop S-Series Planning and Configuration Guide (G06.25+)

VST379.vsd
-
If the enclosures are placed with their appearance sides facing each other,
add 31 inches
If the enclosures are placed with their service sides facing each other,
subtract 31 inches
To a horizontally adjacent enclosure, 75 inches
To a vertically adjacent enclosure, 99 inches
To a diagonally adjacent enclosure, 114 inches
For each additional intervening enclosure, add 23 inches
If you tie the cable down, then stretch it across the service side of its enclosure to the other
cable trough before routing it across a row to another enclosure, add the appropriate length:
Total Cable Length
+
+
+
If this cable will be bundled with a large number of other cables, add extra slack.
For information about what is appropriate for your configuration,
contact your service provider.
+
6 inches of slack (3 inches per cable end)
31inches (cabinet depth)
Standard Measurements
37
+
to group
From group
System Name
/ /
Date
of
Page
Width of service aisle (48 inches minimum)
If cable is installed under a raised floor
Amount of slack for cable, based on depth of raised floor
If cable runs down from a
stacked enclosure in a double-high stack, add 59 inches
single enclosure, or base enclosure in a double-high stack,
add 25 inches
Variable Measurements
If cable runs in overhead cable trough
Distance from top of cabinet to cable trough
If cable runs up from a
stacked enclosure in a double-high stack, add 20 inches
single enclosure, or base enclosure in a double-high stack,
add 54 inches
Cross-Row Cabling Worksheet, SEB to IOMF CRU
+
+
+
+
+
Cable Part Number
