HP NonStop S-Series Planning and Configuration Guide—523303-015
Glossary-1
Glossary
3-phase. Describes a single power source with three output phases (A, B, and C). The
phase difference between any two of the three phases or currents is 120 degrees.
3860 ATM 3 ServerNet adapter (ATM3SA). See ATM 3 ServerNet adapter (ATM3SA).
3861 Ethernet 4 ServerNet adapter (E4SA). See Ethernet 4 ServerNet adapter (E4SA).
3862 Token-Ring ServerNet adapter (TRSA). See Token-Ring ServerNet adapter (TRSA).
3863 Fast Ethernet ServerNet adapter (FESA). See Fast Ethernet ServerNet adapter
(FESA).
3865 Gigabit Ethernet ServerNet adapter (GESA). See Gigabit Ethernet ServerNet
adapter (GESA).
4619 disk drive. An 18-gigabyte, 15,000-rpm, small computer system interface (SCSI) disk
drive for HP NonStop™ S-series servers running G06.06 and later release version
updates (RVUs). The 4619 disk drive can coexist and operate with lower-capacity or
lower-speed drives in the same storage subsystem module.
4637 disk drive. A 36-gigabyte, 10,000-rpm, small computer system interface (SCSI) disk
drive for HP NonStop™ S-series servers running G06.06 and later release version
updates (RVUs).
6740 ServerNet/FX adapter. See ServerNet/FX adapter.
6742 ServerNet/FX 2 adapter. See ServerNet/FX 2 adapter.
6760 ServerNet device adapter (ServerNet/DA). See ServerNet device adapter
(ServerNet/DA).
6761 F-PIC. See fiber-optic plug-in card (F-PIC).
6762 S-PIC. See SCSI plug-in card (S-PIC).
6763 Common Communication ServerNet adapter (CCSA). See Common
Communication ServerNet adapter (CCSA).
A. See ampere (A).
A0CINFO file. A distribution subvolume (DSV) file that contains information about a product
and each of its files, including product and file dependencies, how the files are used
and where they are placed, and which type of processor the product runs on. Every
product and software product revision (SPR) to be managed by Distributed Systems
Management/Software Configuration Manager (DSM/SCM) is distributed in a
subvolume, and that subvolume must contain the product’s A0CINFO file.
